arter97 kernel for Galaxy S3

arter97 kernel for Galaxy S3

This kernel is no longer supported actively!

/* Overview */

Based on stock SHV-E210S kernel source

Supports Android 5.1 Lollipop, CyanogenMod 11.0, Samsung Touchwiz based Android 4.4.4 ROM

Upgraded to the latest Linux

Compiled using latest ARM Linaro-toolchain

Speed improvements

Battery improvements

New CPU Governors

New I/O Schedulers

CPU overclock capability

Color inverting by quadriple tapping on home button

Proper dual-boot functionality

Many more ...

/* Details */

Built using Linaro-toolchain 5.1

Properly upgraded to the latest Linux 3.0.101

Dual-boot functionallity for all supported ROMs

SELinux disabled(permissive)

Kernel compression in newly-improved LZO format

Kernel scheduler improvements

Full unaligned access enabled

Improved memcpy, hrtimer, mutex, cpufreq, memory-management, writeback

Optimized RWSEM, crypto, math drivers

Wi-Fi wakelock reduced

BFQ v7r8, SIO, FIFO, VR, ZEN I/O schedulers added

ZZmoove, Intelliactive CPU governors added

Overclock available to 1600MHz

Controlable, kernel-side implementation of slient camera shutter sound

Touch Wake with Knock-On feature

Deadline I/O Scheduler speed improved

Asynchronous I/O backported from Linux 3.6 with speed improvements

Asynchronous Fsync from hTC ported by faux123

Dynamic Fsync from faux123

Networking performance improved

Disabled MMC-CRC for better NAND performance

ARCH_POWER enabled for better power savings

Fading LED control by AndreiLux

Random driver backported from Linux 4.0+

SCHED_AUTOGROUP enabled for superior multitasking experience

Westwood as default TCP congestion control for best networking performance

Optimized CRC32 & SHA-1 algorithm

Proportional Rate Reduction for TCP

Boeffla Sound Engine 1.6.7

Charger control by AndreiLux

FAT32 latency improved

Android logger control

Memory throttling removed

Default file-system mount option with noatime & nodiratime

Proper, full support for f2fs & backported from Linux 4.2

Switchable sharpness control by AndreiLux, AndiP71

Latest mali graphics libraries

Automatic kernel panic log dumper

Boost-boot for better performance

Sdcardfs extended to all supported ROMs

Android 4.4 KitKat's extra free kbytes tunables added for better memory managements

ARM_UNWIND enabled for better performance

File-system writeback function backported from Linux 3.4 with latency improvements

Compiler profiles backported from Linux 3.16

Kernel module integrated into the ramdisk for better loading speed

Insecure ADB control

TCP's Initial Congestion Window tunables from Android 4.4.3

Power-efficient workqueues backported from linaro-lsk

Deep-discard-trim; FIDTRIM support for ext4 backported from google-3.4

Entropy hook on storage removed for performance

/* More informations */

Based on stock SHV-E210S kernel source

    Samsung has put massive updates in their Android 4.4 kernel compared with Android 4.1 kernel. By being based on stock SHV-E210S kernel source, arter97 kernel is miles ahead of where other CyanogenMod-based kernels are slowly catching up behind.

Dual-booting

    arter97 kernel implements simple yet seamless multi-boot solution that does not need a dedicated recovery. It's also faster, thanks to raw extracted method instead of slow loop mounted images.

    To start, enter recovery(CWM, PhilZ) and flash arter97-multi-boot.zip. The ZIP files you flash afterwards will be stored in the 2nd-ROM slot(/data/arter97_secondrom) until you exit or restart recovery.

    Reboot back to 1st-ROM, and use newly installed 'aSwitch' to control 2nd-ROM. You cannot select between two ROMs on the initial start-up time.

     * 2nd-ROM's /system partition will be always mounted R/W due to its limitations.

     * Backup & restore will not work for 2nd-ROM. Don't try it unless you want your entire device screwed all over.

     * Do not select data wipe on 2nd-ROM installation! 1st-ROM data might be lost instead.

Advanced mDNIe control

    arter97 kernel offers advanced mDNIe control by AndreiLux, leaving every single controls available for the screen in the palm of your hands.

Knock-On

    arter97 kernel offers full Touch Wake functionality(by Ezekeel & Yank555.lu) with additional 'Knock-On' feature. Within the desired timer you set, Touch Wake will only work by double-tapping.

Touch Wake

    Touch Wake has been improved in arter97 kernel. Not only the implementation of 'Knock-On' feature, you can now set a seperate timer on charge, force to also work on physical button pressed.

Compiler

    arter97 kernel uses the latest Linaro-toolchain. Linux kernel's compiler profiles has also been backported from Linux 3.16 for more compiler bug-fixes, performance improvements.

Memory managements

    arter97 kernel is fully upstreamed to the latest Linux 3.0.101. This provides improved stability, performance and memory management. But many developers forget to properly match Samsung's CMA memory management to Linux 3.0.101. arter97 kernel is the only kernel properly upstreamed to Linux 3.0.101 with CMA, meaning better memory management than other kernels.

    If you're using Android 4.4 KitKat, ROM can work together with arter97 kernel which improves memory managements even further.

File-system

    Battery and access speed to /sdcard is also improved by utilizing Samsung's sdcardfs and ditching Google's fuse implementation. Users can disable sdcardfs allowing FolderMount to work properly.

    FAT32 latency is improved, and AIO(Asynchronous I/O) is backported from Linux 3.6 with latency improvements.

f2fs

    arter97 kernel is the first Android kernel(since 2013/08) to feature full f2fs support with selective partitions preferences. If you manage to make a switch from ext4 to f2fs, theoratically, your device's flash storage can perform up-to 2x faster. arter97 kernel also continously backport the latest f2fs from Linux 3.16+. This f2fs will be even more faster, reliable than other Android kernels.

    PhilZ recovery dedicated for f2fs makes users easy to switch. Install kernel and recovery, wipe /data and /cache, that's it.

Boeffla Sound Engine

    Boeffla Sound Engine is the only custom audio engine available in arter97 kernel. Go and download 'Boeffla Sound Control' from Google Play store.

Android logger control

    Android logger, aka logcat can produce a lot of garbage datas even when you don't need them. You can explicitly disable Android logger completely, or make it clear itself when the screen goes off(which is the default).

Mali graphics

    arter97 kernel uses the latest Mali driver available for Samsung's Exynos 4412 phones, r3p2. It also uses the latest Mali blobs from E210S ROM, which is built more recently than GT-I9300 ROMs.

Automatic kernel panic log dumper

    When you use a custom kernel, you may experience unexpected malfunctions like sudden reboots. You should dump the kernel log and report it to the developer to help, but it may be very tiring to manually dumping and sending it. To make your life easier, arter97 kernel automatically dumps kernel log when kernel panic happens, and stores it on /sdcard/arter97.

Kernel-side Camera shutter sound control

    arter97 kernel can force and turn off the speaker while the rear camera is operating. Since this is a kernel-side implementation, it doesn't need any ROM side support. Control available from aTweaks.

Boost-boot

    Boost-boot is a function that can reduce boot-up time up-to 20 seconds. It uses 'performance' CPU governor, 'no-op' I/O scheduler and 1024kB readahead when the device is booting.

aTweaks

    aTweaks is a live-kernel-controller dedicated for arter97 kernel based on STweaks. You can control almost every aspects that arter97 kernel offers. Installing BusyBox before using is recommended.

aSwitch

    aSwitch is a dual-boot settings for arter97 kernel. It can wipe 2nd-ROM's /system, /data and /cache. You can also set /sdcard sharing option within aSwitch.

/* Changelog */

5.0

    pegasusqplus, yankasusq and lulzactiveq CPU governors removed

    pegasusq reworked for better stability

    f2fs updated to Linux 4.2 sources for better stability and performance

    RTL8187 support dropped for better stability

    Network file-systems support dropped for better stability

    Adaptive Body Bias control removed for better stability

    Undervolt control removed for better stability

    Intelli_plug removed for better stability

    Misc commits reverted for better stability

    FPU corruption fixed

    1.7, 1.8 GHz overclock frequency removed

    CFQ I/O Scheduler set as the default for better responsiveness

    Intelliactive set as the default CPU governor

    Partial code of Lazyplug added to intelliactive for better responsiveness

    Zen-tune from Liquorix kernel removed

    Random drivers updated to the latest mainline Linux

    zswap(vnswap) pool percent increased

    AIO regression reverted

    BFQ I/O scheduler updated to v7r8

    LZ4 re-added and updated to be used with vnswap

    Ramdisk updated

    ZZmoove CPU governor updated to v1.0-beta8

4.1

    Now being built with Linaro 5.1 toolchain

    Intelli-plug updated to 4.0

    Various memory improvements (fs/seq_file.c)

    Trim speed on ext4 improved

    Discard option re-enabled for f2fs

        (Jaegeuk Kim says inline kernel handlings for discard is more efficient)

    Userspace trim disabled for f2fs

        (Reduces vold overhead on FITRIM requests)

    Trim fixed for some NAND storage for f2fs

    Support for Samsung Touchwiz Android 4.3 ROMs removed

    Support for Android 5.0 ROMs removed

    Support for Android 5.1 ROMs added

    Installation failure after ROM installation fixed

    Network speed tweaked for LTE models

4.0.3

    Issues with swap configurations fixed

    Misc SELinux logs improved

    Compiler and linker updated

4.0.2

    Latest CyanogenMod 12 ramdisk changes merged

        (Fixes bootloop on latest builds)

4.0.1

    Zen-tune from Liquorix kernel implemented

        (Reduces lags)

    ondemand CPU governor removed

    Few inconsistencies fixed for SHV-E210L

    Hardswap on preload partition added on aTweaks

4.0

    Prevent random enter to recovery

    LPM mode on Android 5.0 Lollipop fixed

    Low-level start-up misc issue fixed

    Revert - "usb cb wake lock", "usb device wake lock" wakelock removed

        (Fixes USB connections)

    Random drivers updated to the latest mainline Linux

    LZO security vulnerability fixed

    Entropy hook on storage removed for performance

    f2fs updated to the latest mainline Linux

    Android 5.0 Lollipop ramdisk updated

4.0-beta6

    f2fs updated to the latest mainline Linux

    Durpy defconfig changes removed

    SHV-E210S_KK_Opensource_Update2.zip merged

    Hybrid support for different HWC implemented

        (Fixes camera initialization issues)

    MobiCore disabled for AOSP

        (Memory optimizations)

    "usb cb wake lock", "usb device wake lock" wakelock removed

        (Experimental workarounds)

4.0-beta5

    f2fs updated to the latest mainline Linux

    sdcardfs extended and enabled with Android 5.0 Lollipop

    PegasusQ set as the default CPU governor for stability

    firelock and full-frequency-usage removed from PegasusQ for performance

    Android 5.0 Lollipop ramdisk updated

    Stability on charging with phone turned off improved

    PhilZ Touch recovery now uses standard VOLD mount points

4.0-beta4

    Removed GPS blobs from 4.0-beta3

        (Fixes GPS on AOSP - you may need to reinstall the entire ROM to fix GPS)

4.0-beta3

    f2fs updated to the latest mainline Linux

    Some cutting-edge compiler optimizations tuned down for stability

    Added L1/L2 cache size paramater optimizations (by JustArchi)

    Support for Android 5.0 reworked

    Support for Android 5.0 Lollipop VPN added

    Support for Android 5.0 Lollipop power consumption calculation added

    Support for Android 5.0 Lollipop idletimer enabled

    Deadline / noop set as the default I/O schedulers

    Incall boost increased to 1000 MHz for more stability

    Ext4 mount option journal_async_commit removed

    Ext4 barrier enabled for better stability

    Now uses TRIM from userspace instead of kernel for performance

    Boeffla sound engine updated to 1.6.7

    Second-phase touch booster removed for stability

    Intell-plug touch booster removed for stability

    BFQ I/O scheduler updated to v7r7

    Installs and uses the working HWC from NamelessROM if on AOSP

    Enables s3cfb fencing on AOSP

        (Fixes graphical glitches)

    MHL sound output issue fixed

    Vnswap on AOSP switch added

    Added GPS blobs from E210SKSUKNK3

    Recovery updated to PhilZ Touch 6.59.0

    Misc performance and stability improvements

    Support for AOSP Android 4.3 ROMs removed

4.0-beta2

    Major speed improvements via new ARM instructions set

    interactive CPU governor re-based to android-3.4

        (Fixes frequency stuck issue)

    ZZmoove v1.0-beta2

    ROW I/O scheduler removed

    Misc block commits reverted

        (Improves overall stability)

    f2fs reworked from ground-up

        (Stability, performance improvements)

    Automatic kernel panic log dumper now stores log on /sdcard/arter97

    RTL8187 support added (integrated)

    SHV-E210L radio issues fixed

    External storage support for Android 5.0 Lollipop enabled

4.0-beta1

    Kernel rebased to Galaxy S3 LTE KitKat source

        (Fixes graphical glitches on Touchwiz ROMs)

    512 MB of vnswap enabled for Touchwiz ROMs

    Intelliactive now the default CPU governor

    Touchwiz Android 4.4.2 support removed

    Back-to-n00t ROM support added

    Android 5.0 Lollipop ROM support added

    Charge during phone-off fixed

    ZZmoove v1.0-beta1

    Interactive governor ported from Galaxy Mega 2

    Powerboost removed

    Deadlock during phone-call fixed

    Toolchain switched to stable Linaro GCC 4.9.2 2014.10

    Recovery updated to PhilZ Touch 6.58.7

    multi-boot updated for fixing AOSP ROM installation

3.1.1

    PM_SUSPEND_FREEZE removed

        (Responsible for all issues related to sleep)

    intelliactive - CPU boost frequency fixed to 1000 MHz

        (Standard for Exynos 441x)

    Misc improvements to freezer, irq and futex

        (Credits to Colin Cross, Sankara S Muthukrishnan, Thomas Gleixner and Francisco Franco)

3.1

    Installation failure on some recovery issue fixed

    ext4: Speedup WB_SYNC_ALL pass called from sync

    Kernel thread: wake up worker only when the worker is idle

    Disable GENTLE_FAIR_SLEEPERS when powerboosted

        (Better UI snappiness)

    Network performance with process_backlog improved

    BusyBox updated

    aSwitch updated to version 2.5

        (Fixes reboot not working on some ROMs)

    Boost CPU frequency on resuming from sleep or screen-off

    PM_SUSPEND_FREEZE fixed

        ("Maybe" fixes some issues with screen not tuning on after voice call)

    Screen-off CPU frequency limit unlocked for intelli-plug users experiencing music studders

    Several more network integration with ROM

    multi-boot.zip updated to version 2.1 fixing 2 or more ZIP files installation

3.0

    Now uses interactive as the default CPU governor, replacing pegasusq

    Now uses more power-efficient PM_SUSPEND_FREEZE on stand-by

    2nd-phase touch boost implemented for much more snappy touch reaction

        (When the screen is touched, CPU frequency is bumped up to 1.2 GHz for 100ms, then down to the default 0.8 GHz)

    Undervolt capability added from Perseus kernel (by AndreiLux)

    aSwitch updated to version 2.4

        (Now correctly reboots after ROM switch)

    multi-boot.zip updated to version 2.0 for much better compatibility

        (Use only with arter97 kernel 3.0 or higher!)

    Misc improvements with memory managements, internal MMC handlings, network including TCP and SELinux

    Wi-Fi module handling improved

    Installation time improved

    ADB on Samsung stock-based Android 4.3 ROM fixed

    ondemand CPU governor power consumption & speed improved

        (Changed calculation of target frequency)

    interactive CPU governor merged from upstream Google 3.0 Git repository

    Tracers within interactive CPU governor removed for better performance

    f2fs re-imported from scratch for bug-fixes

    sched_mc_power_savings now set to 0 for better performance

    ZZmoove CPU governor updated to v0.9-b4 (by ZaneZam)

    AOSP Android 4.4 KitKat ramdisk updated

    CyanogenMod 11's addon.d installed for nightly updates

    Built with updated toolchain

    Recovery updated to PhilZ Touch 6.57.5

    Now correctly applies CPU frequency settings when resuming from throttled state

2.2

    GT-I9300_JB_Opensource_Update14.zip merged

    Power-efficient workqueues backported from linaro-lsk

    Deep-discard-trim; FIDTRIM support for ext4 backported from google-3.4

    Revamped aSwitch, aTweaks icon

    aTweaks typo cleaned

    Removed invalid hotplug lock within aTweaks

    Powerboost routine improved

    SdcardFS switch added

        (for those who are planning to use FolderMount)

    Intelli-plug merged with smart switch

    Intelliactive merged

    Random drivers updated to the latest mainline Linux

    f2fs updated to the latest mainline Linux

    f2fs performance improved with nobarrier option

    BFQ updated to v7r5

    lzo security vulnerabilities patched

    lz4 security vulnerabilities patched

    Reverted busfreq and wakelock commits

    AOSP Android 4.4 KitKat ramdisk updated

    Compiler flags updated

    Built with updated toolchain

    Frandom removed

        (default random drivers are better that now it's merged from mainline Linux)

    io_is_busy is now properly enabled by default

    Recovery updated to PhilZ Touch 6.56.2, ClockworkMod v6.0.5.0

    Support for network file-systems re-added

2.1.3

    UKSM removed

        (responsible for almost all kernel panics happened with previous versions)

    AOSP Android 4.4 KitKat ramdisk updated

    Security vulnerability CVE-2014-3153 fixed(towelroot)

    Recovery updated to PhilZ Touch 6.46.2

2.1.2

    GPIO processing operation reordered

        (faster wake-up)

    SLUB Memory Allocater from Linux 3.3 reverted

        (better stability)

    Debugging functions in SLUB Memory Allocater added by Samsung removed

2.1.1

    Write permissions on external storage fixed

    Recovery malfunction on external storage fixed

    Fixed advanced mDNIe control in aTweaks

    f2fs whitelisted on SELinux to maximize compatibilities

    CMA memory validation on Mali re-enabled

    Android 4.4.3 kernel source code changes applied

    TCP's Initial Congestion Window tunables

        (network performance improvements)

    f2fs updated to the latest mainline Linux

    AOSP Android 4.4 KitKat ramdisk updated

    Recovery initial loading speed improved

    Recovery updated to PhilZ Touch 6.44.9, ClockworkMod v6.0.4.9

    Removed userspace, hotplug, adaptive CPU governors

    Removed support for network file-systems

    Config minimalized for lighter kernel

2.1

    Dedicated custom PhilZ recovery released for f2fs

    Allowing an easy switch to f2fs

    Toolchain switched to stable Linaro GCC 4.9.1 2014.05

    Block backport from Linux 3.3 reverted

         - Fixes kernel panics with Samsung Touchwiz Android 4.4 KitKat

    BFQ updated to v7r4

    Mali graphics driver merged from N7100 Android 4.4 KitKat kernel

    /data/container mount fixed for Samsung Touchwiz Android 4.4 KitKat

    sdcardfs brought up from N7100 Android 4.4 KitKat kernel

    sdcardfs extended to all Android 4.4 KitKat ROMs

         - Better performance and battery

    Installation failure on PhilZ recovery fixed

    Improved installation speed

    Advanced mDNIe control by AndreiLux added

    Touch boost code reverted to stock kernel

         - Use 800 MHz instead of previous 600 MHz

    Ultra KSM with profile configuration added

    zRam with ultra-fast LZ4 compression method added

    Debugging codes within ext4 file-system source code removed

         - Better performance

    CVE-2014-0196 security vulnerability fixed

    Conditional statement for dynamic camera firmware loading

         - Camera fixed for Samsung Touchwiz Android 4.4 KitKat

2.0

    Initial release to XDA developers

/* Disclaimer */

Your warranty is now void.

I am not responsible for bricked devices, dead SD cards,

thermonuclear war, or you getting fired because the alarm app failed. Please

do some research if you have any concerns about features included in this ROM

before flashing it! YOU are choosing to make these modifications, and if

you point the finger at me for messing up your device, I will laugh at you. Hard. A lot.

/* Warning */

Do not redistribute, modify, fetch, extract files used within this project or integrate with other files without my permissions.

Making mirrors, re-uploading to another servers are strictly prohibited with no exceptions.

/* Supported device */

Galaxy S3 3G International (GT-I9300)

Galaxy S3 SK-3G (SHW-M440S)

Galaxy S3 SK-LTE (SHV-E210S)

Galaxy S3 KT-LTE (SHV-E210K)

Galaxy S3 LG-LTE (SHV-E210L)

/* Unsupported device */

Galaxy S3 LTE International (GT-I9305)

/* What you need to know */

'Opensource' does not mean 'no-respect'

Leave credits to original developers



All files for supported devices are integrated into one file

/* FAQ */

I get 'status7' error while installing!

Your recovery is out-dated. Go and install a newer one.

Any recommended kernel settings?

The defaults are the most recommended settings. Try and use the default settings for several days before tweaking it yourself.

No GPU clock controls?

No. I personally don't like exposing GPU clock controls to users. I have no plans of adding these controls to my kernels.

I'm experiencing data-losses, device shutdown while downloading torrents!

Please turn off 'Dynamic Fsync' from aTweaks. Note that this may make your device slower.

Screen mode settings are not working!

mDNIe settings is moved to aTweaks. Please use the settings from there.

My screen color is inverted!

Tap the home-button 4 times. It's a kernel feature, please read the entire post.

The boot animation is laggy after installing this kernel!

The root cause is unknown for now, but it is normal and doesn't affects anything else.

Personal Hotspot is not working after switching to another kernel!

It's due to hostapd binary change. Go and re-flash your ROM.

/* Thanks to */

Samsung

faux123

Yank555.lu

Temasek

AndreiLux

AndiP71

DerTeufel

ZaneZam

JustArchi

Moster2

NamelessROM developers

ckh469

edoko

gokhanmoral

codeworkx

xens0117

franciscofranco

And all the developers, maintainers of CyanogenMod's smdk4x12 kernel!



irendah07

/* Contact */

XDA forum : https://forum.xda-developers.com/galaxy-s3/development/arter97-kernel-galaxy-s3-t2749849

Email : qkrwngud825@gmail.com

Twitter : @arter97

/* Downloads */

arter97 kernel for Galaxy S3

arter97 recovery for Galaxy S3

arter97-multi-boot.zip

/* Installation */

1. Put kernel on you SD card

2. Enter ClockworkMod(or PhilZ) recovery

3. Flash kernel

/* Switch to f2fs */

This step includes a full factory wipe!

Backup your data prior to switch!



You may use arter97 recovery to back-up previous ext4 data to an external storage

and restore it to newly formatted f2fs storage.



Your /system partition(ROM) will stay unwiped at ext4

for no compatibility issues what-so-ever.

You may install any ROM that fits your taste.



1. Install normal ClockworkMod(or PhilZ) recovery

2. Put arter97 recovery on you SD card

3. Enter recovery

4. Flash recovery

5. Reboot recovery

6.1 Select "Mounts and Storage"

6.2. Select "toggle f2fs <-> ext4 migration"

6.3. Select "format /cache"

6.4. Select "f2fs"

6.5. Select "Yes - Format device"

7.1. Select "format /data and /data/media (/sdcard)"

7.2. Select "Yes - Format"

7.3. Select "f2fs"

7.4. Select "Yes - Format device"

8. Reboot





Browse all files
